Image Modal Prototypes

Base UI Dialog for accessibility. Conditional render swaps thumbnail for a hidden placeholder when open, so only one layoutId element exists at a time. aspectRatio on the card wrapper prevents collapsed-height snapshots. Skeleton fallback for loading polish.

Base UI Popover with modal mode. Trigger stays in DOM (no swap). Positioner overridden to fixed-center. layoutId animates from anchor position to center.

Base UI Popover with modal mode. Trigger stays in DOM (no swap). Positioner overridden to fixed-center. layoutId animates from anchor position to center.

Open

No Base UI dialog/popover primitives for layout. layoutId with AnimatePresence and createPortal. Manual accessibility handling. Follows Motion's documented shared layout animation pattern.

What we tried

A reference of every approach attempted across the full history of this component, documenting what worked, what broke, and why.

layoutId on card wrapper, conditional swap (thumbnail unmounts)Partial

Works on second open; first open collapses to ~40px because the <img> hasn't painted and the card has no height hint. Motion captures the FLIP "to" snapshot before the browser resolves intrinsic dimensions.

layoutId on card + aspectRatio on card wrapperWorks

Fixes the first-open collapse. aspectRatio on the motion.div itself (not just the inner <img>) gives Motion a correct layout rect to snapshot, regardless of image load state.

layoutId on inner motion.img (not the card)Broken

Image animates but card styling (border-radius, shadow, padding) doesn't transition — it pops. Only the layoutId element gets the FLIP animation; the card wrapper is a different element.

layout on child motion.img inside layoutId parentBroken

Causes stretching/distortion. The child's layout animation applies its own scale correction that compounds with the parent's layoutId scale, creating a double-transform.

layout="position" on motion.imgPartial

Position animates but size snaps instantly. layout="position" only animates translate, not scale. For a lightbox, the size change IS the animation.

layoutRoot on a fixed container wrapping the modalBroken

Broke centering and caused offset issues. layoutRoot accounts for page scroll inside fixed containers, but combined with Dialog.Viewport (also fixed with its own centering), it added an extra projection layer that warped coordinate math.

LayoutGroup wrapping thumbnail + modalNo effect

No observable improvement. LayoutGroup synchronizes layout animations across sibling components that re-render independently. Here, thumbnail and modal are in the same React tree and re-render together via the same open state.

Parent motion.div with initial={{ opacity: 0 }} wrapping the layoutId cardBroken

Modal appeared blank/invisible on open, then popped in. Motion's layoutId crossfade already manages opacity between old and new elements. A separate parent opacity animation compounded with the crossfade (0 × crossfade = invisible).

objectFit: contain on modal imageBroken

Empty whitespace below/beside the image. object-fit: contain letterboxes the image when the container's aspect ratio doesn't exactly match. Since aspectRatio already ensures correct proportions, object-fit was redundant and harmful.

Dialog.Popup with h-full w-full + no centering on itselfBroken

Modal card pinned to top-left, not centered. The Popup filled the entire viewport but had no items-center justify-center. The parent Viewport's centering applied to the Popup container, but the card inside sat at flex-start.
